Description Commercial data Item number 2866310 Packing unit 1 pc Minimum order quantity 1 pc Sales key CMP Product key CMPU13 Catalog page Page 266 (C-4-2019) GTIN 4046356729192 Weight per piece (incl. packing) 187,02 g Weight per piece (excl. packing) 147 g Customs tariff number 85044095 Country of origin VN UNO-PS/1AC/24DC/ 30W – Power supply unit Technical data Input data AC operation Parameter Specification Nominal Input Voltage Range 100 V AC … 240 V AC Input Voltage Range 85 V AC … 264 V AC Input Voltage Range AC 85 V AC … 264 V AC Voltage Type of Supply Voltage AC Inrush Current < 30 A (typ.) Inrush Current Integral (I2 t) < 0.4 A2 s (typ.) AC Frequency Range 50 Hz … 60 Hz Frequency range (fN ) 50 Hz … 60 Hz ±10 % Mains Buffering Time > 25 ms (120 V AC) > 115 ms (230 V AC) Current Consumption typ. 0.8 A (100 V AC) typ. 0.4 A (240 V AC) Nominal Power Consumption 72.1 VA Protective Circuit Transient surge protection; Varistor Power Factor (cos phi) 0.47 Typical Response Time < 1 s Input Fuse 2 A (slow-blow, internal) Recommended Breaker for Input Protection 6 A … 16 A (Characteristics B, C, D, K) Output data Efficiency typ. 87 % (120 V AC) typ. 88 % (230 V AC) Output characteristic HICCUP Nominal output voltage 24 V DC Nominal output current (IN) 1.25 A (-25 °C … 55 °C) Derating 55 °C … 70 °C (2.5 %/K) Feedback voltage resistance < 35 V DC Protection against overvoltage (OVP) ≤ 35 V DC Control deviation < 1% (change in load, static 10% … 90%) < 2% (change in load, dynamic 10% … 90%) < 0.1% (change in input voltage ±10%) Residual ripple < 60 mVPP (with nominal values) Short-circuit-proof yes Output power 30 W Maximum no-load power dissipation < 0.3 W Power loss nominal load max. < 5 W Rise time < 0.5 s (UOUT (10 % … 90 %)) Response time < 2 ms Connection in parallel yes, for redundancy and increased capacity UNO-PS/1AC/24DC/ 30W – Power supply unit Connection in series yes Connection data Input Connection method Screw connection Conductor cross section, rigid min. 0.2 mm² Conductor cross section, rigid max. 2.5 mm² Conductor cross section flexible min. 0.2 mm² Single conductor/flexible terminal point with ferrule with plastic sleeve, max. 2.5 mm² Single conductor/flexible terminal point with ferrule without plastic sleeve, min. 0.2 mm² Single conductor/flexible terminal point with ferrule without plastic sleeve, max. 2.5 mm² Conductor cross section AWG min. 24 Conductor cross section AWG max. 14 Stripping length 8 mm Screw thread M3 Tightening torque, min 0.5 Nm Tightening torque, max 0.6 Nm Output Connection method Screw connection Conductor cross section, rigid min. 0.5 mm² Conductor cross section, rigid max. 6 mm² Conductor cross section flexible min. 0.5 mm Conductor cross section flexible max. 4 mm² Conductor cross section, AWG min 20 Conductor cross section AWG max. 10 Stripping length 14 mm Screw thread M3 Tightening torque, min 0.5 Nm Tightening torque, max 0.6 Nm UNO-PS/1AC/24DC/ 30W – Power supply unit Signaling Types of signaling LED Electrical properties Number of phases 1.00 Insulation voltage output / PE 4 kV AC (type test) 3 kV AC (routine test) Product properties Product type Power supply Product family UNO POWER MTBF (IEC 61709, SN 29500) > 1158000 h (40 °C) Insulation characteristics Protection class II (in closed control cabinet) Degree of pollution 2 Dimensions Width 22.5 mm Height 90 mm Depth 84 mm Installation dimensions Installation distance right/left 0 mm / 0 mm Installation distance top/bottom 30 mm / 30 mm Mounting Mounting type DIN rail mounting Assembly note alignable: 0 mm horizontally, 30 mm vertically Mounting position Horizontal DIN rail NS 35, EN 60715 With protective coating No Material specifications Flammability rating according to UL 94 (housing / terminal blocks) V0 Housing material Plastic Housing material Polycarbonate Foot latch material POM (Polyoxymethylene) Environmental and real-life conditions Ambient conditions Degree of protection IP20 Ambient temperature (operation) -25 °C … 70 °C (> 55° C derating : 2.5%/K) Ambient temperature (storage/transport) -40 °C … 85 °C Ambient temperature (start-up type tested) -40 °C Climatic class 3K22 (in accordance with EN 60721-3-3) UNO-PS/1AC/24DC/ 30W – Power supply unit Max. permissible relative humidity (operation) ≤ 95 % (at 25 °C, non-condensing) Shock 18 ms, 30g, in each space direction (according to IEC 60068-2- 27) Vibration (operation) < 15 Hz, amplitude ±2.5 mm (according to IEC 60068-2-6) 15 Hz … 150 Hz, 2.3g, 90 min Standards and regulations Standard – Electronic equipment for use in electrical power installations and their assembly into electrical power installations EN 50178/VDE 0160 (PELV) Standard – Limitation of mains harmonic currents EN 61000-3-2 Standard – Electrical safety IEC 62368-1 (SELV) Standard – Safety extra-low voltage IEC 62368-1 (SELV) und EN 60204-1 (PELV) Standard – Safe isolation DIN VDE 0100-410 Standard – Safety of transformers EN 61558-2-16 Approval – requirement of the semiconductor industry with regard to mains voltage dips EN 61000-4-11 Mains voltage dips Standard designation Requirement of the semiconductor industry with regard to mains voltage dips Standards/specifications SEMI F47 – 0706 (180 V AC) Approvals CSA CAN/CSA-C22.2 No. 60950-1-07 CSA-C22.2 No. 107.1-01 CSA CAN/CSA-C22.2 No. 213 Class I, Division 2, Groups A, B, C, D T4 (Hazardous Location) UL approvals UL/C-UL listed UL 508 NEC Class 2 as per UL 1310 UL/C-UL Listed ANSI/ISA-12.12.01 Class I, Division 2, Groups A, B, C, D T4 (Hazardous Location) UL approvals UL/C-UL Recognized UL 60950-1 Conformity/Approvals SIL in accordance with IEC 61508 0 Performance level according to ISO 13849 without EMC data Low Voltage Directive Conformance with Low Voltage Directive 2014/35/EC EMC Requirements for Noise Emission EN 61000-6-3 EN 61000-6-4 EMC Requirements for Noise Immunity EN 61000-6-1 EN 61000-6-2 Electromagnetic Compatibility Conformance with EMC Directive 2014/30/EU Electrostatic discharge Standards/Regulations EN 61000-4-2 UNO-PS/1AC/24DC/ 30W – Power supply unit Electrostatic discharge Contact discharge 6 kV(Test Level 3) Discharge in air 8 kV (Test Level 3) Comments Criterion B Electromagnetic HF field Standards/regulations EN 61000-4-3 Electromagnetic HF field Frequency Range 80 MHz … 1 GHz Test Field Strength 10 V/m (Test Level 3) Frequency range 1 GHz … 6 GHz Test field strength 10 V/m (Test Level 3) Comments Criterion A Fast transients (burst) Standards/regulations EN 61000-4-4 Fast transients (burst) Input 4 kV (Test Level 4 – asymmetrical) Output 4 kV (Test Level 4 – asymmetrical) Comments Criterion B Surge voltage load (surge) Standards/regulations EN 61000-4-5 Surge voltage load (surge) Input 1 kV (Test Level 2 – symmetrical) 2 kV (Test Level 3 – asymmetrical) Output 0.5 kV (Test Level 1 – symmetrical) 1 kV (Test Level 2- asymmetrical) Comments Criterion B Conducted interference Standards/regulations EN 61000-4-6 Conducted interference Frequency Range 0.15 MHz … 80 MHz Comments Criterion A Voltage 10 V (Test Level 3) Conducted interference Input/Output asymmetrical Frequency Range 0.15 MHz … 80 MHz Comments Criterion A Voltage 10 V (Test Level 3) Voltage dips Standards/regulations EN 61000-4-11 Voltage 230 V AC Frequency 50 Hz Voltage dip 70 % UNO-PS/1AC/24DC/ 30W – Power supply unit Number of periods 25 periods Additional text Class 3 Comments Criterion A Voltage dip 40 % Number of periods 10 periods Additional text Class 3 Comments Criterion A Voltage dip 0 % Number of periods 1 period Additional text Class 3 Comments Criterion A Emitted interference Standards/regulations EN 61000-6-3 Radio interference voltage in acc. with EN 55011 EN 55011 (EN 55022) class B used in industry and residential area / EMC 1 Emitted radio interference in acc. with EN 55011 EN 55011 (EN 55022) class B used in industry and residential area / EMC 1 Criteria Criterion A Normal operating behavior within the specified limits. Criterion B Temporary impairment to operational behavior that is corrected by the device itself UNO-PS/1AC/24DC/ 30W – Power supply unit Classifications ECLASS ECLASS-11.0 27040701 ECLASS-13.0 27040701 ECLASS-12.0 27040701 ETIM ETIM 9.0 EC002540 UNSPSC UNSPSC 21.0 39121000 UNO-PS/1AC/24DC/ 30W – Power supply unit Environmental product compliance EU RoHS Fulfills EU RoHS substance requirements Yes Exemption 6(c), 7(c)-I China RoHS Environment friendly use period (EFUP) EFUP-25 An article-related China RoHS declaration table can be found in the download area for the respective article under “Manufacturer declaration”. For all articles with EFUP-E, no China RoHS declaration table issued and required EU REACH SVHC REACH candidate substance (CAS No.) Lead(CAS: 7439-92-1) SCIP 05b42b3b-0bf7-4e8c-94e6-1ecaf9319514 EF3.0 Climate Change CO2e kg 3,657 kg CO2e UNO-PS/1AC/24DC/ 30W – Power supply unit Accessories UNO-DIODE/5-24DC/2X10/1X20 – Redundancy module Redundancy module, 5 V – 24 V DC, 2 x 10 A, 1 x 20 A. CBMC E4 24DC/1-4A NO – Electronic circuit breaker Multi-channel electronic circuit breaker for protecting four loads at 24 V DC in the event of overload and short circuit. With electronic locking of the set nominal currents. For installation on DIN rails. UNO-PS/1AC/24DC/ 30W – Power supply unit CBMC E4 24DC/1-10A NO – Electronic circuit breaker Multi-channel electronic circuit breaker for protecting four loads at 24 V DC in the event of overload and short circuit. With electronic locking of the set nominal currents. For installation on DIN rails. PLT-SEC-T3-230-FM-UT – Type 3 surge protection device Type 2/3 surge protection, consisting of protective plug and base element with screw connection. For single-phase power supply network with integrated status indicator and remote signaling. Nominal voltage: 230 V AC/DC UNO-PS/1AC/24DC/ 30W – Power supply unit PLT-SEC-T3-24-FM-UT – Type 3 surge protection device Type 3 surge protection, consisting of protective plug and base element, with integrated status indicator and remote signaling for single-phase power supply networks. Nominal voltage: 24 V AC/DC
